METAL FORMING

PRESS BRAKE

EB 2160

ISITAN EB 2160 NC Press Brake Capacity

Bending force is 60ton, full length bending capacity is 4mm, bending length is 2100mm. Distance between feet 1010mm, Throat depth 320mm.

ISITAN EB 2160 NC Press Brake General Features

Y axis angle adjustment with motor and NC control, Manual crowning possibility thanks to PROMECAM used for fast mold disassembly and assembly, Front support arms that can be easily moved with linear slide and bearing system, Clamping and fixing bolts for centering the lower mold.

Materials Used in ISITAN EB 2160 NC Press Brake

Compact, low-maintenance HAWE or REXROTH hydraulic system unit located at the top of the machine, remote service solution thanks to European SIEMENS and PIZZATO, BALLUF electrical equipment, LEUZE brand security system and bending in different forms with learning mode

TECHNICAL DETAILS

STANDARD FEATURES

Bending system with Double Cylinder on the upper table. Static and dynamic rigidity provided, strong construction with steel frame and upper table material. Upper table movement supported by easily adjustable fiber slide bearings. Durable balancing spindle and eccentric bearings that aid parallelism. Stroke controlled angle adjustment mechanism with mechanical-stop system and motor control. High stroke and front opening values that facilitate the use of different bending molds. Easy tonnage adjustment with pressure switch and stop at lower stroke point via NC control. Hydraulic safety system against excessive pressure rise. Double speed working system: free fall, slow bend and fast return. Safety enabled foot pedal with emergency stop connected to the NC Controller, enables safe work environment and compatible with CE Compact, low maintenance needed HAWE or REXROTH hydraulic system unit located at the top of the machine. Service solution with remote connection with European origin SIEMENS and PIZZATO, BALLUF electrical equipments. LEUZE brand security system, in the front area enables different forms with learning mode. NC control unit, which can write standard 500 programs / 200 lines in each, And easy save and load programs from USB. Standard upper and lower molds. Motorized X back gauge with high speed and programmed via NC control supported with linear guideways: 600 mm gauge distance and 0.2 mm operating precision, Y AXIS Angle Setting by Motor and NC Controller available Quick-release PROMECAM upper Die clamping system for partial and quick disassembly. Manual crowning system which can be adjusted with the help of wedge from the upper die holders. Easily floating arm control panel. Front support arms that can be easily moved with linear slide and bearing systems. Tightening and fixing bolts to center the bottom die Sensetive prgrammable retreat function on Backgauge to avoid collision

TECHNICAL SPECIFICATIONS UNIT ISITAN EB 2160 NC PRESS BRAKE
Bending Power ton 60
Working Length mm 2100
Distance of Frames mm 1700
Mobile Piston Working Stroke mm 160
Throat depth mm 320
Idle Speed (mm/s) 90
Bending Speed (mm/s) 10
Lightcurtain mm 380
Motor power kw 7,5
Motor X-axis kw 0,75
Angle Setting motor kw 0,18
Motor R Axis kw 0,25
Dimensions (L-W-H) mm 2350x1600x2235
Back gauge length mm 600
Weight kg 4340
